| 齒輪目錄 Contents of Pinions |
| DIN |
型號 Code | 精度等級
DIN 3962 | 材料
Material | 齒輪齒型
Type | 齒面處理
Teeth Treatment | 硬度處理
Hardness | 模 數
Module | 详情頁碼
Page |
| MHGH | DIN 6 | SCM415
SCM440 | 斜齒左斜
Helical Left Hand
19°31'42" | 齒研
Teeth Ground | HRC 50-55° | 1.5, 2, 3, 4, 5, 6, 8, 10 | 點擊查看 |
| MHGH-L | DIN 6 | SCM415
SCM440 | HRC 50-55° | 1.5, 2.5, 3 | 點擊查看 |
| MHSH | DIN 7 | SCM415
SCM440 | 磨削
Skiving | HRC 50-55° | 1.5, 2, 3, 4, 5, 6, 8, 10 | 點擊查看 |
| CHM | DIN 8 | S45C
S50C | 精銑
Milled | * | 1.5, 2, 3, 4, 5, 6, 8, 10 | 點擊查看 |
| MHMH | DIN 10 | SCM415
SCM440 | HRC 50-55° | 1.5, 2, 3, 4, 5, 6, 8, 10 | 點擊查看 |
| MSGH | DIN 6 | SCM415
SCM440 | 直齒
Straight | 齒研
Teeth Ground | HRC 50-55° | 2, 3, 4, 5, 6, 8 | 點擊查看 |
| MSSH | DIN 7 | SCM415
SCM440 | 磨削
Skiving | HRC 50-55° | 2, 3, 4, 5, 6, 8 | 點擊查看 |
| CSM | DIN 8 | S45C
S50C | 精銑
Milled | * | 1, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10 | 點擊查看 |
| MSMH | DIN 10 | SCM415
SCM440 | HRC 50-55° | 1, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10 | 點擊查看 |
| MHFGH | DIN 6 | SCM415
SCM440 | 法蘭斜齒齒輪
Flange Helical | 齒研
Teeth Ground | HRC 50-55° | 2, 3, 4, 5 | 點擊查看 |
| JIS |
型號 Code | 精度等級
JIS | 材料
Material | 齒輪齒型
Type | 齒面處理
Teeth Treatment | 硬度處理
Hardness | 模 數
Module | 詳情頁碼
Page |
| MHGH | JIS 2 (N6) | SCM415
SCM440 | 斜齒左斜
Helical Left Hand 21°30' | 齒研
Teeth Ground | HRC 50-55° | 1, 1.5, 2, 2.5, 3 | 點擊查看 |
| CHM | JIS 4 (N8) | S45C
S50C | 斜齒左斜
Helical Left Hand 15° | 精銑
Milled | * | 2，3 | 點擊查看 |
| MSGH | JIS 2 (N6) | SCM415
SCM440 | 直齒
Straight | 齒研
Teeth Ground | HRC 50-55° | 1, 1.5, 2, 2.5, 3, 4 | 點擊查看 |
| CSSH | JIS 3 (N7) | S45C
S50C | 磨削
Skiving | HRC 50-55° | 1, 1.5, 2, 2.5, 3, 4, 5, 6 | 點擊查看 |
| CSM | JIS 4 (N8) | S45C
S50C | 精銑
Milled | * | 1, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10 | 點擊查看 |
| CP |
型號 Code | 精度等級 JIS | 材料
Material | 齒輪齒型
Type | 齒面處理
Teeth Treatment | 硬度處理Hardness | 周 節 CP | 詳情頁碼
Page |
| MSGH-CP | DIN 6 | SCM415
SCM440 | 直齒
Straight | 齒研
Teeth Ground | HRC 50-55° | 5, 7.5, 10, 15, 20 | 點擊查看 |
| MSSH-CP | JIS 3 (N7) | SCM415
SCM440 | 磨削
Skiving | HRC 50-55° | 5,101,520 | 點擊查看 |
| CSM-CP | JIS 4 (N8) | S45C
S50C | 精銑
Milled | * | 5,101,520 | 點擊查看 |
